SKU: HFL.3530.EU
HFL3530 Budget Needle Roller Clutch Type One Way Bearing 35x42x30mm
HFL3530 Budget Needle Roller Clutch Type One Way Bearing 35x42x30mm
Regular price
CHF 11.00
ex VAT
Regular price
Sale price
CHF 11.00
ex VAT
In stock
Price Break
10+
CHF 8.20
19+
CHF 7.74
29+
CHF 7.64
39+
CHF 7.55
49+
CHF 7.46
74+
CHF 7.37
99+
CHF 6.91
199+
CHF 6.82
249+
CHF 6.72
499+
CHF 6.63
999+
CHF 6.45
Share this product
Description
Description
|
Budget Metric Needle Roller Clutch Bearings: Designed to transmit torques in one direction and freewheel in the opposite direction. One-way clutches consist of a thin-walled, drawn outer ring with a series of ramps on the inside diameter, plastic cages, springs and needle rollers. They are supplied pre-greased with lithium soap grease. |
- Brand / Quality:
- EU Budget - Economy Quality
- Inside Diameter:
- 35mm
- Outside Diameter:
- 42mm
- Width:
- 30mm
Technical
Technical
| Fw | 35mm |
|---|---|
| D | 42mm |
| C | 30mm (Tolerance: 0/-0.3) |
| r min | 0.3mm |
| Permissable torque | 121 Nm |
| Speed (rotating shaft) | 3900 rpm |
| Speed (rotating outer ring) | 3900 rpm |
| Maximum permissable radial load | 12200 N |
| Limiting load | 18800 N/min |
| Weight | 58 g |
