SKU: HGZ80-JCS
JCS HGZ80 Zinc Plated Steel Hi-Grip Hose Clip Adjustment Range 60-80mm Band Width 13mm
JCS HGZ80 Zinc Plated Steel Hi-Grip Hose Clip Adjustment Range 60-80mm Band Width 13mm
Regular price
CHF 1.60
ex VAT
Regular price
Sale price
CHF 1.60
ex VAT
In stock
Price Break
5+
CHF 1.12
10+
CHF 0.96
20+
CHF 0.88
50+
CHF 0.80
100+
CHF 0.64
500+
CHF 0.56
1000+
CHF 0.48
Couldn't load pickup availability
Description
Description
Zinc Plated Steel Hi-Grip Worm Drive Hose Clips: Used for a wide variety of domestic, automotive and industrial applications, the standard Hi-Grip hose clip is made from mild steel, electroplated, passivated and tested to EN9227. Hi-Grip general-purpose worm drive hose clips are widely regarded for their quality, durability and ability to withstand a great deal of abuse. They are manufactured to exceed BS5315, which has the highest requirements of any of the international standards and tests sealing ability, clamping force and torque.
- Brand / Quality:
- JCS - High Quality
- Width:
- 13mm
- Min Adjustment Range:
- 60mm
- Max Adjustment Range:
- 80mm
Technical
Technical
| BS No. | 80 |
|---|---|
| Adjustment Range (mm) | 60-80mm |
| Adjustment Range (inch) | 2-3/8 - 3-1/8 inch |
| A | 13mm |
| B | 20mm |
| C | 12mm |
| D | 16mm |
| E | 13mm |
| F | 0.9mm |
| Screw | 7mm A/F |
| Recommended Torque Nm | 6Nm |
| Recommended Torque lb-in | 54lb-in |
