SKU: HP90-8M-30-DRIVEFLEX
Drive-Flex P90-8M-30 - 8mm Pitch 90 Tooth Flangeless HTD Type Cast Iron Pilot Bore Timing Pulley for 30mm Wide Belts
Drive-Flex P90-8M-30 - 8mm Pitch 90 Tooth Flangeless HTD Type Cast Iron Pilot Bore Timing Pulley for 30mm Wide Belts
Regular price
CHF 99.43
ex VAT
Regular price
Sale price
CHF 99.43
ex VAT
In stock
Price Break
5+
CHF 98.44
10+
CHF 94.46
20+
CHF 92.47
50+
CHF 89.49
100+
CHF 87.50
500+
CHF 82.53
1000+
CHF 69.60
Couldn't load pickup availability
Description
Description
HTD Pilot Bore Timing Pulley: High Torque Drive (HTD) timing pulleys are available in both taper and pilot bore. The pulleys depending on the size are made from either Aluminium 6082, C45 Steel with black oxide treated surface or Cast Iron EN-GJL-200 and black phosphate. Where applicable flanges are made from S235JR Steel. Timing belt life can be increased with the proper pulley reducing running costs of your machinery.
Benefits: Available in a wide range of diameters and number of teeth along with standard widths.
- Brand / Quality:
- Drive-Flex - High Quality
- Number of Teeth:
- 90
- Pitch:
- 8mm
- Item Type:
- Pilot Bore Pulley
- Maximum Belt Width:
- 30mm
Technical
Technical
| d Pilot Bore (Nominal) | 15mm |
|---|---|
| Pitch | 8mm |
| Belt Width | 30mm |
| Dp | 229.18mm |
| De | 227.81mm |
| Dm | 100mm |
| F | 38mm |
| L | 48mm |
| Number of Teeth | 90 |
| Material | Cast Iron |
| Type | 3 Pilot Bore |
