SKU: HRC180B+HRC180B+HRC180I-MB
Major Brand HRC180B Coupling Assembly Pilot Bored Nominal 25mm Max Bore 80mm with Natural Rubber Insert
Major Brand HRC180B Coupling Assembly Pilot Bored Nominal 25mm Max Bore 80mm with Natural Rubber Insert
Regular price
CHF 110.00
ex VAT
Regular price
Sale price
CHF 110.00
ex VAT
Equivalent to: HRC180B HRC180B HRC180I DRC180B+DRC180B+DRC180I
In stock
Price Break
10+
CHF 87.33
19+
CHF 82.43
29+
CHF 81.45
39+
CHF 80.47
49+
CHF 79.48
74+
CHF 78.50
99+
CHF 73.60
199+
CHF 72.61
249+
CHF 71.63
499+
CHF 70.65
999+
CHF 68.69
Description
Description
Branded HRC Coupling Assembly Pilot Bored with Natural Rubber Insert: These semi-elastic couplings are designed for general use purpose use. The fully machined outside diameters allow alignment by simple straight edge methods. The shaft connection is "fail-safe" due to interacting dog design.
Supplied as a complete coupling assembly. The assembly comprises of 2 coupling flanges and a matching insert. The coupling is the BB type which has pilot bores and will require machining to your application requirements.
Do you need a Fire Resistant Antistatic (F.R.A.S) rubber insert. See links below.
Equivalent: HRC180B HRC180B HRC180I DRC180B+DRC180B+DRC180I
- Brand / Quality:
- Major Brand - High Quality
Technical
Technical
| Nominal Torque | 950 Nm |
|---|---|
| Overall Diameter A | 180mm |
| Hub Diameter B | 125mm |
| Assembled Length F | 73.5mm |
| Insert Bore Dia E | 77mm |
| Insert Width G | 49.5mm |
| Parallel Misalignment | 0.4mm |
| Assembly Weight | 18.446kg |
| L width | 189.5mm<sup>3</sup> |
| B Type - Max Bore | 80mm |
| B Type - Pilot Bore | 25mm |
| B Type - Keyway Screw Size | M10mm |
| B Type - Shoulder Width D | 58mm |
| B Type - Hub Width C | 70.5mm |
| Max Power at 100 rpm | 9.95 kW |
| Max Power at 200 rpm | 19.9 kW |
| Max Power at 400 rpm | 39.8 kW |
| Max Power at 600 rpm | 59.7 kW |
| Max Power at 720 rpm | 71.6 kW |
| Max Power at 800 rpm | 79.6 kW |
| Max Power at 960 rpm | 95.5 kW |
| Max Power at 1200 rpm | 119 kW |
| Max Power at 1440 rpm | 143 kW |
| Max Power at 1600 rpm | 159 kW |
| Max Power at 1800 rpm | 179 kW |
| Max Power at 2000 rpm | 199 kW |
| Max Power at 2200 rpm | 219 kW |
| Max Power at 2400 rpm | 239 kW |
| Max Power at 2600 rpm | 259 kW |
| Max Power at 2880 rpm | 286 kW |
| Max Power at 3000 rpm | 298 kW |
| Nominal Torque (Nm) | 950 Nm |
| Max Torque | 2350 Nm |
