SKU: HT144-8M-30-PD
PowerDrive TL144-8M-30 - 8mm Pitch 144 Tooth Flangeless HTD Type Cast Iron Taper Bore Timing Pulley for 30mm Wide Belts
PowerDrive TL144-8M-30 - 8mm Pitch 144 Tooth Flangeless HTD Type Cast Iron Taper Bore Timing Pulley for 30mm Wide Belts
Regular price
CHF 129.75
ex VAT
Regular price
Sale price
CHF 129.75
ex VAT
In stock
Price Break
10+
CHF 115.48
19+
CHF 108.99
29+
CHF 107.69
39+
CHF 106.40
49+
CHF 105.10
74+
CHF 103.80
99+
CHF 97.31
199+
CHF 96.02
249+
CHF 94.72
499+
CHF 93.42
999+
CHF 90.83
Couldn't load pickup availability
Description
Description
HTD Taper Bore Timing Pulleys: High torque drive (HTD) timing pulleys are available in both taper and pilot bore. The pulleys depending on the size are made from either Aluminium 6082, C45 Steel with black oxide treated surface or Cast Iron EN-GJL-200 and black phosphate. Where applicable flanges are made from S235JR Steel. Timing belt life can be increased with the proper pulley reducing running costs of your machinery.
Benefits: Available in a wide range of diameters and number of teeth along with standard widths.
- Brand / Quality:
- Powerdrive - High Quality
- Number of Teeth:
- 144
- Pitch:
- 8mm
- Item Type:
- Taper Bore Pulley
- Maximum Belt Width:
- 30mm
Technical
Technical
| --- | Pulley Dimensions |
|---|---|
| Pitch | 8mm |
| Number of Teeth | 144 |
| Type | 8 Taper Bore |
| Bush | <a href="advanced_search_result.php?sort=2a&search_in_description=0&keywords=2517+tapered+locking+bush ">2517 Click Here</a> |
| Dp | 366.69mm |
| De | 365.32mm |
| Dm | 125mm |
| Di | 336mm |
| F | 38mm |
| S | 45mm |
| P | 7mm |
| Weight | 9.00kg |
