• SKF KMK12 Lock Nut with Integral Locking Device M60x2mm
  • SKF KMK12 Lock Nut with Integral Locking Device M60x2mm
  • SKF KMK12 Lock Nut with Integral Locking Device M60x2mm
1 3

SKU: KMK12-SKF

SKF KMK12 Lock Nut with Integral Locking Device M60x2mm

SKF KMK12 Lock Nut with Integral Locking Device M60x2mm
CHF 67.00 ex VAT
CHF 67.00 ex VAT
Sale Sold out

In stock

Price Break
10+ CHF 53.37
19+ CHF 50.37
29+ CHF 49.77
39+ CHF 49.17
49+ CHF 48.57
74+ CHF 47.97
99+ CHF 44.97
199+ CHF 44.38
249+ CHF 43.78
499+ CHF 43.18
999+ CHF 41.98
Request Quotation

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
SKF Precision KMK Lock Nuts: These lock nuts have an integral locking device consisting of a grub screw against a pressure plate that has the thread profile machined on it, When tightened there is no possibility of damaging the threads and mounting and dismounting are a simple operation. The outer perimeter of the nut has the usual slots for use of a nut spanner or socket. No additional lock washers or clips are required.
Benefits: Efficient, secure, inexpensive, removable and re-useable
Brand / Quality:
SKF - High Quality
Thread Size:
M60x2
Technical
d1 74mm
d3 80mm
B 13mm
b 7mm
h 3mm
Axial load capacity 95 kN
Loosening torque 188 Nm
Weight 0.2 kg
G M60x2
Designation KMK12
Locking device HN12
Grub screw M8
Grub screw torque 18 Nm
