SKU: KMTA18-SKF

SKF KMTA18 Precision Locking Nut with Locking Pins M90x2mm

SKF KMTA18 Precision Locking Nut with Locking Pins M90x2mm
CHF 221.00 ex VAT
CHF 221.00 ex VAT
Sale Sold out

In stock

Price Break
10+ CHF 175.68
19+ CHF 165.81
29+ CHF 163.83
39+ CHF 161.86
49+ CHF 159.89
74+ CHF 157.91
99+ CHF 148.04
199+ CHF 146.07
249+ CHF 144.10
499+ CHF 142.12
999+ CHF 138.17
Request Quotation

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
SKF Precision KMTA Lock Nuts: Manufactured with standard ISO threads and a relieved external diameter primarily used for precision bearing installation. The inclusion of 3 locking pins mounted at 120 degrees around the perimeter and diagonally to the threads and allow for minor radial alignment adjustments.
Benefits: Efficient, secure, inexpensive, removable and re-useable
Brand / Quality:
SKF - High Quality
Thread Size:
M90x2
Technical
G M90x2
d2 120mm
d3 110mm
d4 93mm
B 32mm
J1 108mm
J2 17mm
N1 6.4mm
N2 8mm
Axial load capacity 680 kN
Loosening torque 720 Nm
Weight 1.2 kg
Spanner B120-130
Grub Screw M10
Screw torque 35 Nm
Name KMTA18
