SKU: MFC2-RHP
RHP MFC2 Four Bolt Round Cast Iron Flanged Bearing Unit and 2 inch Insert
RHP MFC2 Four Bolt Round Cast Iron Flanged Bearing Unit and 2 inch Insert
Regular price
CHF 158.75
ex VAT
Regular price
Sale price
CHF 158.75
ex VAT
In stock
Price Break
10+
CHF 141.29
19+
CHF 133.35
29+
CHF 131.76
39+
CHF 130.18
49+
CHF 128.59
74+
CHF 127.00
99+
CHF 119.06
199+
CHF 117.48
249+
CHF 115.89
499+
CHF 114.30
999+
CHF 111.13
Couldn't load pickup availability
Description
Description
|
RHP MFC Series Heavy Duty 4 Bolt Round Cast Iron Housing Units: Four bolt round cast iron bearing unit supplied with a sealed full width bearing insert fitted and includes a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft after installation. |
- Brand / Quality:
- RHP - High Quality
- Inside Diameter:
- 50.8mm = 2 inch
- Style:
- MFC
- Pitch Circle Diameter:
- 136.53mm = 5.375 (5-3/8) inch
Technical
Technical
| Bore | 2 inch |
|---|---|
| L | 6.374 inch |
| H | 4.5 inch |
| J | 5.375 inch |
| G | 0.4375 inch |
| A1 | 1.562 inch |
| A4 | 0.748 inch |
| A5 | 0.252 inch |
| B | 2.187 inch |
| s | 0.877 inch |
| d1 | 2.709 inch |
| Dynamic load | 43500 N |
| Static load | 29200 N |
| Rec max speed | 3100 rpm |
| Weight | 3 kg |
| Insert | <a href="advanced_search_result.php?keywords=1055-2G+insonly">1055-2G Click Here</a> |
| Casting group | 5 |
| Grease nipple thread | 1/4 UNF, 1/4 inch x 28 TPI |
