SKU: MSF1055-2K-RHP
RHP MSF1055-2K Imperial Four Bolt Square Cast Iron Flange Housing and 2 inch Bore Taper Sleeve Insert
In stock
Price Break
Couldn't load pickup availability
Description
|
RHP MSF Series Heavy Duty 4 Bolt Square Cast Iron Housings: Bearing units supplied with a full width sealed heavy duty bearing insert fitted in the cast iron housing and includes a grease nipple to facilitate re-lubrication. The bearing has a taper bore to accommodate the taper sleeve which is tightened using a lock nut to secure to the shaft after installation, the locknut is subsequently secured with the tab washer. |
- Brand / Quality:
- RHP - High Quality
- Inside Diameter:
- 50.8mm = 2 inch
- Style:
- MSF
- Bolt Hole Centres:
- 129.997mm = 5.118 inch
Technical
| Bore | 2 inch |
|---|---|
| L | 6.374 inch |
| H | 5000 inch |
| J | 5.118 inch |
| G | 0.625 inch |
| A | 1.72 inch |
| A1 | - inch |
| A4 | 0.689 inch |
| B | - inch |
| s | - inch |
| d1 | - inch |
| Dynamic load cr | 43500 N |
| Static load Cor | 29200 N |
| Rec max speed | 3100 rpm |
| Weight | 4 kg |
| Insert | <a href="advanced_search_result.php?keywords=1055K+insonly">1055K Click Here</a> |
| Casting group | 6 |
| Grease nipple thread | 1/4 UNF, 1/4 inch x 28 TPI |
