SKU: MSF2.3/16-RHP
RHP MSF2-3/16 Imperial Four Bolt Square Cast Iron Flange Housing and 2-3/16 inch Bore Grub Screw Insert
RHP MSF2-3/16 Imperial Four Bolt Square Cast Iron Flange Housing and 2-3/16 inch Bore Grub Screw Insert
Regular price
CHF 186.26
ex VAT
Regular price
Sale price
CHF 186.26
ex VAT
In stock
Price Break
10+
CHF 165.77
19+
CHF 156.46
29+
CHF 154.60
39+
CHF 152.73
49+
CHF 150.87
74+
CHF 149.01
99+
CHF 139.70
199+
CHF 137.83
249+
CHF 135.97
499+
CHF 134.11
999+
CHF 130.38
Couldn't load pickup availability
Description
Description
|
RHP MSF Series Heavy Duty 4 Bolt Square Cast Iron Housings: Bearing units supplied with a full width sealed heavy duty bearing insert fitted in the cast iron housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has two grub screws to allow tightening against the shaft after installation. |
- Brand / Quality:
- RHP - High Quality
- Inside Diameter:
- 55.56mm = 2.187 (2-3/16) inch
- Style:
- MSF
- Bolt Hole Centres:
- 143.002mm = 5.63 inch
Technical
Technical
| Bore | 2-3/16 inch |
|---|---|
| L | 6.87 inch |
| H | 5.437 inch |
| J | 5.63 inch |
| G | 0.625 inch |
| A | 1.874 inch |
| A1 | 2.901 inch |
| A4 | 0.689 inch |
| B | 2.562 inch |
| s | 1.002 inch |
| d1 | 2.966 inch |
| Dynamic load cr | 48000 N |
| Static load Cor | 33000 N |
| Rec max speed | 2800 rpm |
| Weight | 4.7 kg |
| Insert | <a href="advanced_search_result.php?keywords=1060-2-3/16G+insonly">1060-2-3/16G Click Here</a> |
| Casting group | 7 |
| Grease nipple thread | 1/4 UNF, 1/4 inch x 28 TPI |
