SKU: MSF3.7/16-RHP
RHP MSF3-7/16 Imperial Four Bolt Square Cast Iron Flange Housing and 3-7/16 inch Bore Grub Screw Insert
RHP MSF3-7/16 Imperial Four Bolt Square Cast Iron Flange Housing and 3-7/16 inch Bore Grub Screw Insert
Regular price
CHF 570.44
ex VAT
Regular price
Sale price
CHF 570.44
ex VAT
In stock
Price Break
10+
CHF 507.69
19+
CHF 479.17
29+
CHF 473.47
39+
CHF 467.76
49+
CHF 462.06
74+
CHF 456.35
99+
CHF 427.83
199+
CHF 422.13
249+
CHF 416.42
499+
CHF 410.72
999+
CHF 399.31
Couldn't load pickup availability
Description
Description
|
RHP MSF Series Heavy Duty 4 Bolt Square Cast Iron Housings: Bearing units supplied with a full width sealed heavy duty bearing insert fitted in the cast iron housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has two grub screws to allow tightening against the shaft after installation. |
- Brand / Quality:
- RHP - High Quality
- Inside Diameter:
- 87.31mm = 3.437 (3-7/16) inch
- Style:
- MSF
- Bolt Hole Centres:
- 171.45mm = 6.75 inch
Technical
Technical
| Bore | 3-7/16 inch |
|---|---|
| L | 8.406 inch |
| H | 7.736 inch |
| J | 6.75 inch |
| G | 0.75 inch |
| A | 2.429 inch |
| A1 | 3.967 inch |
| A4 | 1.024 inch |
| B | 3.781 inch |
| s | 1.564 inch |
| d1 | 4.396 inch |
| Dynamic load cr | 96000 N |
| Static load Cor | 71500 N |
| Rec max speed | 1900 rpm |
| Weight | 13.2 kg |
| Insert | <a href="advanced_search_result.php?keywords=1090-3-7/16G+insonly">1090-3-7/16G Click Here</a> |
| Casting group | 12 |
| Grease nipple thread | 1/4 UNF, 1/4 inch x 28 TPI |
