SKU: MSF3-RHP
RHP MSF3 Imperial Four Bolt Square Cast Iron Flange Housing and 3 inch Bore Grub Screw Insert
RHP MSF3 Imperial Four Bolt Square Cast Iron Flange Housing and 3 inch Bore Grub Screw Insert
Regular price
CHF 364.00
ex VAT
Regular price
Sale price
CHF 364.00
ex VAT
In stock
Price Break
10+
CHF 289.00
20+
CHF 272.76
30+
CHF 269.51
40+
CHF 266.27
50+
CHF 263.02
75+
CHF 259.77
100+
CHF 243.54
200+
CHF 240.29
250+
CHF 237.04
500+
CHF 233.79
1000+
CHF 227.30
Share this product
Description
Description
|
RHP MSF Series Heavy Duty 4 Bolt Square Cast Iron Housings: Bearing units supplied with a full width sealed heavy duty bearing insert fitted in the cast iron housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has two grub screws to allow tightening against the shaft after installation. |
- Brand / Quality:
- RHP - High Quality
- Inside Diameter:
- 76.2mm = 3 inch
- Style:
- MSF
- Bolt Hole Centres:
- 152.4mm = 6 inch
Technical
Technical
| Bore | 3 inch |
|---|---|
| L | 7.736 inch |
| H | 6.831 inch |
| J | 6 inch |
| G | 0.75 inch |
| A | 2.165 inch |
| A1 | 3.499 inch |
| A4 | 0.906 inch |
| B | 3.25 inch |
| s | 1.314 inch |
| d1 | 3.878 inch |
| Dynamic load cr | 71500 N |
| Static load Cor | 54500 N |
| Rec max speed | 2150 rpm |
| Weight | 9.3 kg |
| Insert | <a href="advanced_search_result.php?keywords=1080-3G+insonly">1080-3G Click Here</a> |
| Casting group | 10 |
| Grease nipple thread | 1/4 UNF, 1/4 inch x 28 TPI |
