SKU: MSF30-RHP
RHP MSF30 Metric Four Bolt Square Cast Iron Flange Housing and 30mm Bore Grub Screw Insert
RHP MSF30 Metric Four Bolt Square Cast Iron Flange Housing and 30mm Bore Grub Screw Insert
Regular price
CHF 69.00
ex VAT
Regular price
Sale price
CHF 69.00
ex VAT
In stock
Price Break
10+
CHF 54.75
20+
CHF 51.67
30+
CHF 51.06
40+
CHF 50.44
50+
CHF 49.83
75+
CHF 49.21
100+
CHF 46.14
200+
CHF 45.52
250+
CHF 44.91
500+
CHF 44.29
1000+
CHF 43.06
Share this product
Description
Description
|
RHP MSF Series Heavy Duty 4 Bolt Square Cast Iron Housings: Bearing units supplied with a full width sealed heavy duty bearing insert fitted in the cast iron housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has two grub screws to allow tightening against the shaft after installation. |
- Brand / Quality:
- RHP - High Quality
- Inside Diameter:
- 30mm
- Style:
- MSF
- Bolt Hole Centres:
- 92mm
Technical
Technical
| Bore | 30mm |
|---|---|
| L | 117.5mm |
| H | 95.3mm |
| J | 92mm |
| G | 12mm |
| A | 31.4mm |
| A1 | 46.41mm |
| A4 | 12.7mm |
| B | 42.88mm |
| s | 17.53mm |
| d1 | 46.69mm |
| Dynamic load cr | 25700 N |
| Static load Cor | 15300 N |
| Rec max speed | 4500 rpm |
| Weight | 1.7 kg |
| Insert | <a href="advanced_search_result.php?keywords=1035-30G+insonly">1035-30G Click Here</a> |
| Casting group | 2 |
| Grease nipple thread | 1/4 UNF, 1/4 inch x 28 TPI |
