SKU: MSF70-RHP
RHP MSF70 Metric Four Bolt Square Cast Iron Flange Housing and 70mm Bore Grub Screw Insert
RHP MSF70 Metric Four Bolt Square Cast Iron Flange Housing and 70mm Bore Grub Screw Insert
Regular price
CHF 297.00
ex VAT
Regular price
Sale price
CHF 297.00
ex VAT
In stock
Price Break
10+
CHF 236.27
20+
CHF 223.00
30+
CHF 220.34
40+
CHF 217.69
50+
CHF 215.03
75+
CHF 212.38
100+
CHF 199.10
200+
CHF 196.45
250+
CHF 193.79
500+
CHF 191.14
1000+
CHF 185.83
Share this product
Description
Description
|
RHP MSF Series Heavy Duty 4 Bolt Square Cast Iron Housings: Bearing units supplied with a full width sealed heavy duty bearing insert fitted in the cast iron housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has two grub screws to allow tightening against the shaft after installation. |
- Brand / Quality:
- RHP - High Quality
- Inside Diameter:
- 70mm
- Style:
- MSF
- Bolt Hole Centres:
- 152.4mm
Technical
Technical
| Bore | 70mm |
|---|---|
| L | 196.5mm |
| H | 158.5mm |
| J | 152.4mm |
| G | 20mm |
| A | 51.3mm |
| A1 | 80.9mm |
| A4 | 23mm |
| B | 77.77mm |
| s | 33.37mm |
| d1 | 92mm |
| Dynamic load cr | 66000 N |
| Static load Cor | 49500 N |
| Rec max speed | 2300 rpm |
| Weight | 8.6 kg |
| Insert | <a href="advanced_search_result.php?keywords=1075-70G+insonly">1075-70G Click Here</a> |
| Casting group | 9 |
| Grease nipple thread | 1/4 UNF, 1/4 inch x 28 TPI |
