SKU: MSF80-RHP
RHP MSF80 Metric Four Bolt Square Cast Iron Flange Housing and 80mm Bore Grub Screw Insert
RHP MSF80 Metric Four Bolt Square Cast Iron Flange Housing and 80mm Bore Grub Screw Insert
Regular price
CHF 218.00
ex VAT
Regular price
Sale price
CHF 218.00
ex VAT
In stock
Price Break
10+
CHF 173.66
20+
CHF 163.90
30+
CHF 161.95
40+
CHF 160.00
50+
CHF 158.05
75+
CHF 156.10
100+
CHF 146.34
200+
CHF 144.39
250+
CHF 142.44
500+
CHF 140.49
1000+
CHF 136.58
Share this product
Description
Description
|
RHP MSF Series Heavy Duty 4 Bolt Square Cast Iron Housings: Bearing units supplied with a full width sealed heavy duty bearing insert fitted in the cast iron housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has two grub screws to allow tightening against the shaft after installation. |
- Brand / Quality:
- RHP - High Quality
- Inside Diameter:
- 80mm
- Style:
- MSF
- Bolt Hole Centres:
- 171.45mm
Technical
Technical
| Bore | 80mm |
|---|---|
| L | 213.5mm |
| H | 184mm |
| J | 171.45mm |
| G | 20mm |
| A | 54.3mm |
| A1 | 89.64mm |
| A4 | 26mm |
| B | 85.72mm |
| s | 34.18mm |
| d1 | 106.02mm |
| Dynamic load cr | 83000 N |
| Static load Cor | 64000 N |
| Rec max speed | 2000 rpm |
| Weight | 11.1 kg |
| Insert | <a href="advanced_search_result.php?keywords=1085-80G+insonly">1085-80G Click Here</a> |
| Casting group | 11 |
| Grease nipple thread | 1/4 UNF, 1/4 inch x 28 TPI |
