SKU: MSF85-RHP
RHP MSF85 Metric Four Bolt Square Cast Iron Flange Housing and 85mm Bore Grub Screw Insert
RHP MSF85 Metric Four Bolt Square Cast Iron Flange Housing and 85mm Bore Grub Screw Insert
Regular price
CHF 536.00
ex VAT
Regular price
Sale price
CHF 536.00
ex VAT
In stock
Price Break
10+
CHF 426.64
20+
CHF 402.67
30+
CHF 397.88
40+
CHF 393.08
50+
CHF 388.29
75+
CHF 383.50
100+
CHF 359.53
200+
CHF 354.74
250+
CHF 349.94
500+
CHF 345.15
1000+
CHF 335.56
Share this product
Description
Description
|
RHP MSF Series Heavy Duty 4 Bolt Square Cast Iron Housings: Bearing units supplied with a full width sealed heavy duty bearing insert fitted in the cast iron housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has two grub screws to allow tightening against the shaft after installation. |
- Brand / Quality:
- RHP - High Quality
- Inside Diameter:
- 85mm
- Style:
- MSF
- Bolt Hole Centres:
- 171.45mm
Technical
Technical
| Bore | 85mm |
|---|---|
| L | 213.5mm |
| H | 196.5mm |
| J | 171.45mm |
| G | 20mm |
| A | 61.7mm |
| A1 | 100.76mm |
| A4 | 26mm |
| B | 96.04mm |
| s | 39.73mm |
| d1 | 111.66mm |
| Dynamic load cr | 96000 N |
| Static load Cor | 71500 N |
| Rec max speed | 1900 rpm |
| Weight | 13.2 kg |
| Insert | <a href="advanced_search_result.php?keywords=1090-85G+insonly">1090-85G Click Here</a> |
| Casting group | 12 |
| Grease nipple thread | 1/4 UNF, 1/4 inch x 28 TPI |
