SKU: NKS50-MB
Major Brand NKS50 Needle Roller Bearing With Flanges without Shaft Sleeve 50x65x22mm
Major Brand NKS50 Needle Roller Bearing With Flanges without Shaft Sleeve 50x65x22mm
Regular price
CHF 36.00
ex VAT
Regular price
Sale price
CHF 36.00
ex VAT
In stock
Price Break
10+
CHF 28.59
19+
CHF 26.98
29+
CHF 26.66
39+
CHF 26.34
49+
CHF 26.02
74+
CHF 25.70
99+
CHF 24.09
199+
CHF 23.77
249+
CHF 23.45
499+
CHF 23.13
999+
CHF 22.48
Description
Description
|
Needle Roller Bearing with Flanges: Manufactured with flanges (annular rings) in the outside housing to locate the needle roller cage, supplied without inner ring as they are commonly used on hardened shafts, has annular groove and oil hole for lubrication Benefits: Economical solution, supplied without inner ring, non separable, can be used with a wide range of inner rings |
- Brand / Quality:
- Major Brand - High Quality
- Inside Diameter:
- 50mm
- Outside Diameter:
- 65mm
- Width:
- 22mm
Technical
Technical
| Fw | 50mm |
|---|---|
| D | 65mm |
| C | 22mm |
| Dynamic load | 42900 N |
| Static load | 72000 N |
| Fatigue load limit Pu | 9150 N |
| Speed in grease | 5600 rpm |
| Speed in oil | 8000 rpm |
| r1r2 | 1mm |
| Da max | 60mm |
| ra max | 1mm |
| Seal | CR50x65x8CRW1R |
| Weight | 160 g |
