SKU: NKS70-MB
Major Brand NKS70 Needle Roller Bearing With Flanges without Shaft Sleeve 70x90x28mm
Major Brand NKS70 Needle Roller Bearing With Flanges without Shaft Sleeve 70x90x28mm
Regular price
CHF 46.00
ex VAT
Regular price
Sale price
CHF 46.00
ex VAT
In stock
Price Break
10+
CHF 36.28
19+
CHF 34.24
29+
CHF 33.83
39+
CHF 33.42
49+
CHF 33.02
74+
CHF 32.61
99+
CHF 30.57
199+
CHF 30.16
249+
CHF 29.75
499+
CHF 29.35
999+
CHF 28.53
Description
Description
|
Needle Roller Bearing with Flanges: Manufactured with flanges (annular rings) in the outside housing to locate the needle roller cage, supplied without inner ring as they are commonly used on hardened shafts, has annular groove and oil hole for lubrication Benefits: Economical solution, supplied without inner ring, non separable, can be used with a wide range of inner rings |
- Brand / Quality:
- Major Brand - High Quality
- Inside Diameter:
- 70mm
- Outside Diameter:
- 90mm
- Width:
- 28mm
Technical
Technical
| Fw | 70mm |
|---|---|
| D | 90mm |
| C | 28mm |
| Dynamic load | 68200 N |
| Static load | 120000 N |
| Fatigue load limit Pu | 15600 N |
| Speed in grease | 4000 rpm |
| Speed in oil | 5600 rpm |
| r1r2 | 1.1mm |
| Da max | 83.5mm |
| ra max | 1mm |
| Seal | CR70x95x10CRW1R |
| Weight | 380 g |
