SKU: NKXR30Z-EU
NKXR30Z Budget Needle Roller Thrust Bearing with Cover 30x42x30mm
NKXR30Z Budget Needle Roller Thrust Bearing with Cover 30x42x30mm
Regular price
CHF 58.00
ex VAT
Regular price
Sale price
CHF 58.00
ex VAT
In stock
Price Break
10+
CHF 45.72
19+
CHF 43.15
29+
CHF 42.64
39+
CHF 42.12
49+
CHF 41.61
74+
CHF 41.10
99+
CHF 38.53
199+
CHF 38.01
249+
CHF 37.50
499+
CHF 36.99
999+
CHF 35.96
Description
Description
|
Budget Needle Roller / Ball Roller Thrust Combination: Of a none separable design, the outer ring with integral housing washer and integral needle roller cage assembly. Benefits: High thrust loading, easily mounted |
- Brand / Quality:
- EU Budget - Economy Quality
- Inside Diameter:
- 30mm
- Outside Diameter:
- 42mm
- Width:
- 30mm
- Seals / Shields:
- Metal Shields
Technical
Technical
| Fw | 30mm |
|---|---|
| D | 42mm |
| C | 30mm |
| Dynamic load | 22900 N |
| Static load | 39000 N |
| Axial dynamic load | 27000 N |
| Axial static load | 78000 N |
| Fatigue load limit radial Pu | 4800 N |
| Fatigue load limit axial Pu | 7650 N |
| Min load factor A | 0.49 |
| Speed in grease | 2000 rpm |
| Speed in oil | 3000 rpm |
| C1 | 11mm |
| C2 | 9.5mm |
| d | 30mm |
| D2 | 48.2mm |
| r1r2 min | 0.6mm |
| da | 42.7mm |
| ra max | 0.6mm |
| rb max | 0.3mm |
| di | 25mm |
| F | 30mm |
| B1 | 20mm |
| Inner ring | IR25x30x20 |
| Weight | 140 g |
