SKU: NKXR35Z-MB
Major Brand NKXR35Z Needle Roller Thrust Bearing without Cover 35x47x30mm
Major Brand NKXR35Z Needle Roller Thrust Bearing without Cover 35x47x30mm
Regular price
CHF 75.00
ex VAT
Regular price
Sale price
CHF 75.00
ex VAT
In stock
Price Break
10+
CHF 59.69
19+
CHF 56.34
29+
CHF 55.67
39+
CHF 55.00
49+
CHF 54.33
74+
CHF 53.66
99+
CHF 50.30
199+
CHF 49.63
249+
CHF 48.96
499+
CHF 48.29
999+
CHF 46.95
Description
Description
|
Needle Roller / Ball Roller Thrust Combination: Of a none separable design, the outer ring with integral housing washer and integral needle roller cage assembly. Benefits: High thrust loading, easily mounted |
- Brand / Quality:
- Major Brand - High Quality
- Inside Diameter:
- 35mm
- Outside Diameter:
- 47mm
- Width:
- 30mm
Technical
Technical
| Fw | 35mm |
|---|---|
| D | 47mm |
| C | 30mm |
| Dynamic load | 24600 N |
| Static load | 45000 N |
| Axial dynamic load | 29000 N |
| Axial static load | 93000 N |
| Fatigue load limit radial Pu | 5600 N |
| Fatigue load limit axial Pu | 9150 N |
| Min load factor A | 0.69 |
| Speed in grease | 1900 rpm |
| Speed in oil | 2800 rpm |
| C1 | 12mm |
| C2 | 9mm |
| d | 35 |
