SKU: NU315ECP/VL0241-SKF
SKF NU315ECPVL0241 Insocoat Cylindrical Roller Bearing 75x160x37mm
SKF NU315ECPVL0241 Insocoat Cylindrical Roller Bearing 75x160x37mm
Regular price
CHF 1,138.73
ex VAT
Regular price
Sale price
CHF 1,138.73
ex VAT
In stock
Price Break
10+
CHF 1,013.47
19+
CHF 956.53
29+
CHF 945.15
39+
CHF 933.76
49+
CHF 922.37
74+
CHF 910.98
99+
CHF 854.05
199+
CHF 842.66
249+
CHF 831.27
499+
CHF 819.89
999+
CHF 797.11
Couldn't load pickup availability
Description
Description
|
SKF Insocoat Bearings: Special application bearings that are electrically insulated and capable of withstanding voltages up to 1000v, a layer of aluminium oxide (100µm thickness) Benefits: Electrically insulated |
- Brand / Quality:
- SKF - High Quality
- Inside Diameter:
- 75mm
- Outside Diameter:
- 160mm
- Width:
- 37mm
- Seals / Shields:
- None
- Clearance:
- * Standard
Technical
Technical
| d | 75mm |
|---|---|
| D | 160mm |
| B | 37mm |
| Dynamic load C | 280 kN |
| Static load Co | 265 kN |
| Fatigue load limit Pu | 33.5 kN |
| Reference speed | 4500 rpm |
| Limiting speed | 5300 rpm |
| Weight | 3.3 kg |
| D1 | 136mm |
| F | 95mm |
| r1r2 min | 2.1mm |
| r1r4 min | 2.1mm |
| s | 1.8mm |
| da min | 87mm |
| da max | 92mm |
| db min | 97mm |
| Da min | 141mm |
| Da max | 148mm |
| ra max | 2mm |
| rb max | 2mm |
| kr | 0.15 |
