SKF NU318ECP Single Row Cylindrical Roller Bearing with Polyamide Cage 90x190x43mm
SKF NU318ECP Single Row Cylindrical Roller Bearing with Polyamide Cage 90x190x43mm
Regular price
CHF 290.00
ex VAT
Regular price
Sale price
CHF 290.00
ex VAT
In stock
Price Break
10+
CHF 230.43
19+
CHF 217.49
29+
CHF 214.90
39+
CHF 212.31
49+
CHF 209.72
74+
CHF 207.13
99+
CHF 194.18
199+
CHF 191.59
249+
CHF 189.01
499+
CHF 186.42
999+
CHF 181.24
Description
Description
|
SKF NU Series Single Row Cylindrical Roller Bearings: The outer ring of this type has two integral flanges around which the cage and rollers are assembled, the inner raceway has no flanges permitting the ease of assembly and allowing axial movement in either direction. Benefits: Axial displacement tolerant, ease of assembly and fitting |
- Brand / Quality:
- SKF - High Quality
- Inside Diameter:
- 90mm
- Outside Diameter:
- 190mm
- Width:
- 43mm
- Seals / Shields:
- None
- Clearance:
- * Standard
Technical
Technical
| d | 90mm |
|---|---|
| D | 190mm |
| B | 43mm |
| Dynamic load C | 365 kN |
| Static load Co | 360 kN |
| Fatigue load limit Pu | 43 kN |
| Reference speed | 3800 rpm |
| Limiting speed | 4500 rpm |
| Weight | 5.25 kg |
| Alt cage | J.M.ML |
| d1 | 124mm |
| D1 | 162mm |
| F,E | 113.5mm |
| r1r2 min | 3mm |
| r3r4 min | 3mm |
| S | 2.5mm |
| da min | 104mm |
| da max | 110mm |
| db | 116mm |
| Da max | 176mm |
| ra max | 2.5mm |
| rb max | 2.5mm |
| kr | 0.15 |
| Angle ring | HJ318EC |
| Angle Ring Weight | 0.6 kg |
| B1 | 12mm |
| B2 | 18.5mm |
