SKU: P96-H-300
P96-H-300 - 1/2 inch Pitch 96 Tooth Pilot Bored Cast Iron Timing Pulley for 3 inch Wide Belts
P96-H-300 - 1/2 inch Pitch 96 Tooth Pilot Bored Cast Iron Timing Pulley for 3 inch Wide Belts
Regular price
CHF 212.70
ex VAT
Regular price
Sale price
CHF 212.70
ex VAT
Equivalent to: P96H300
In stock
Price Break
10+
CHF 189.30
19+
CHF 178.67
29+
CHF 176.54
39+
CHF 174.41
49+
CHF 172.29
74+
CHF 170.16
99+
CHF 159.53
199+
CHF 157.40
249+
CHF 155.27
499+
CHF 153.14
999+
CHF 148.89
Couldn't load pickup availability
Description
Description
Imperial Pilot Bore Timing Pulley: Imperial timing pulleys are available in both taper and pilot bore. The pulleys depending on the size are made from either Aluminium 6082, C45 Steel with black oxide treated surface or Cast Iron EN-GJL-200 and black phosphate. Where applicable flanges are made from S235JR Steel. Timing belt life can be increased with the proper pulley reducing running costs of your machinery.
Benefits: Available in a wide range of diameters and number of teeth along with standard widths.
Equivalent: P96H300
- Brand / Quality:
- Drive-Flex - High Quality
- Teeth:
- 96
- Material:
- Cast Iron
- Belt Width Approx:
- 76.2mm = 3 inch
- Pitch:
- 12.7mm = 0.5 (1/2) inch
- Item Type:
- Flangeless Pilot Bored Pulley
Technical
Technical
| No. teeth | 96 |
|---|---|
| Dp | 388.09mm |
| De | 386.71mm |
| Dm | 120mm |
| F | 85.7mm |
| L | 100mm |
| d | 28 |
| Material | Cast Iron |
| Bore | Pilot Bored |
| Belt Width | 76.2mm = 3 inch |
| Pitch | 12.7mm = 0.5 (1/2) inch |
