SKU: PCZH5-JCS
JCS PCZH5 Hi-Temp Zinc Plated Steel P-Clip with TPE Liner Band 5mm Closed Diameter
JCS PCZH5 Hi-Temp Zinc Plated Steel P-Clip with TPE Liner Band 5mm Closed Diameter
Regular price
CHF 1.07
ex VAT
Regular price
Sale price
CHF 1.07
ex VAT
In stock
Price Break
5+
CHF 0.75
10+
CHF 0.64
20+
CHF 0.59
50+
CHF 0.54
100+
CHF 0.43
500+
CHF 0.37
1000+
CHF 0.32
Couldn't load pickup availability
Description
Description
High-Temperature Zinc Plated Steel P-Clips with TPE160 Liner: JCS rubber-lined P-Clips are tough and durable, providing a simple and secure fixing solution for even the most challenging of environments. Supplied with a TPE rubber liner which prevents chafing or damage to the surface of the item being clamped. The P-Clip band features a special strengthening rib that keeps the clips flush with the surface to which it is bolted. Zinc Plated version is heavily electro-zinc plated on all surfaces including the edges for the very best corrosion resistance. UV and ozone resistant TPE rubber liner absorbs vibration and prevents chafing of pipe or cable.
- Brand / Quality:
- JCS - High Quality
- Outside Diameter:
- 5mm
- Width:
- 16mm
Technical
Technical
| BS.No | 5 |
|---|---|
| Fastening | M6 |
| Dia Closed | 5mm |
| A | 6mm |
| B | 15mm |
| C | 0.9mm |
| D | 6.6mm |
| E | 12.6mm |
| F | 16mm |
| G | 7mm |
| Liner | TPE 160 (grey) |
| Service Temperature | -50 deg C to +160 deg C |
