SKU: PHR-2-3/4
Major Brand PHR2-3/4 Hex Head Plain Hi-Roller Bearing 2-3/4 inch Outside Diameter
Major Brand PHR2-3/4 Hex Head Plain Hi-Roller Bearing 2-3/4 inch Outside Diameter
Regular price
CHF 137.00
ex VAT
Regular price
Sale price
CHF 137.00
ex VAT
Equivalent to: PHR-275-A PLR-2-3/4 PCF-2-3/4
In stock
Price Break
3+
CHF 108.94
4+
CHF 102.82
9+
CHF 101.59
19+
CHF 100.37
29+
CHF 99.14
39+
CHF 97.92
49+
CHF 91.80
59+
CHF 90.58
249+
CHF 89.35
499+
CHF 88.13
999+
CHF 85.68
Description
Description
|
Plain Hi-Roller Bearing: Designed for applications where both radial and thrust loading are present. These bearings are tightly sealed with an expansion plug on one end and radial contact lip seals on the bearings. They are capable of running at much higher speeds than needle bearing cam followers. Benefits: Ideal for use in environments where dust or high moisture is present. |
Equivalent: PHR-275-A PLR-2-3/4 PCF-2-3/4
- Brand / Quality:
- Major Brand - High Quality
- Outside Diameter:
- 69.85mm = 2.75 (2-3/4) inch
- Width:
- 42.86mm = 1.687 (1-11/16) inch
Technical
Technical
| A | 2.75 inch |
|---|---|
| B | 1.687 inch |
| C | 1 inch |
| D | 2.25 inch |
| E | 1.5 inch |
| Thread class 2A F | 1-14 UNS |
| G | 1.25 inch |
| S | 0.062 inch |
| Basic dynamic rating | 5190 lbs |
| Dynamic thrust load rating | 1400 lbs |
| Max static capacity | 2270 lbs |
