SKU: PHR-6
Major Brand PHR6 Hex Head Plain Hi-Roller Bearing 6 inch Outside Diameter
Major Brand PHR6 Hex Head Plain Hi-Roller Bearing 6 inch Outside Diameter
Regular price
CHF 1,016.00
ex VAT
Regular price
Sale price
CHF 1,016.00
ex VAT
Equivalent to: PHR-600-A PLR-6 PCF-6
In stock
Price Break
3+
CHF 808.62
4+
CHF 763.19
9+
CHF 754.11
19+
CHF 745.02
29+
CHF 735.94
39+
CHF 726.85
49+
CHF 681.42
59+
CHF 672.34
249+
CHF 663.25
499+
CHF 654.17
999+
CHF 636.00
Description
Description
|
Plain Hi-Roller Bearing: Designed for applications where both radial and thrust loading are present. These bearings are tightly sealed with an expansion plug on one end and radial contact lip seals on the bearings. They are capable of running at much higher speeds than needle bearing cam followers. Benefits: Ideal for use in environments where dust or high moisture is present. |
Equivalent: PHR-600-A PLR-6 PCF-6
- Brand / Quality:
- Major Brand - High Quality
- Outside Diameter:
- 152.4mm = 6 inch
- Width:
- 76.2mm = 3 inch
Technical
Technical
| A | 6 inch |
|---|---|
| B | 3 inch |
| C | 2.5 inch |
| D | 5.5 inch |
| E | 3.25 inch |
| Thread class 2A F | 2-1/2-12 UN |
| G | 3.25 inch |
| S | 0.062 inch |
| Basic dynamic rating | 35840 lbs |
| Dynamic thrust load rating | 33100 lbs |
| Max static capacity | 56400 lbs |
