SKU: SIL40TXE-2LS-SKF
SKF SIL40TXE2LS Left Hand Steel / PTFE Fabric Lined Plain Female Rod End M42x3 Thread
SKF SIL40TXE2LS Left Hand Steel / PTFE Fabric Lined Plain Female Rod End M42x3 Thread
Regular price
CHF 310.13
ex VAT
Regular price
Sale price
CHF 310.13
ex VAT
In stock
Price Break
10+
CHF 276.02
19+
CHF 260.51
29+
CHF 257.41
39+
CHF 254.31
49+
CHF 251.21
74+
CHF 248.10
99+
CHF 232.60
199+
CHF 229.50
249+
CHF 226.39
499+
CHF 223.29
999+
CHF 217.09
Couldn't load pickup availability
Description
Description
- Brand / Quality:
- SKF - High Quality
- Thread Size:
- M42x3
- Thread M / F:
- Female
- Thread Direction:
- Left Hand
- Inside Diameter:
- 40mm
- Material:
- PTFE Fabric Lined
Technical
Technical
| d | 40mm |
|---|---|
| d2 max | 94mm |
| G 6H | M42x3 |
| B | 28mm |
| C1 max | 24mm |
| h1 | 145mm |
| a | 7deg |
| Dynamic load C | 280 kN |
| Static load Co | 166 kN |
| Weight | 2.3 kg |
| dk | 53mm |
| d4 | 58mm |
| l3 min | 65mm |
| l4 max | 194mm |
| l5 | 25mm |
| l7 min | 46mm |
| r1 min | 0.6mm |
| w h14 | 50mm |
