SKU: SIL50TXE-2LS-SKF
SKF SIL50TXE2LS Left Hand Steel / PTFE Fabric Lined Plain Female Rod End M52x3 Thread
SKF SIL50TXE2LS Left Hand Steel / PTFE Fabric Lined Plain Female Rod End M52x3 Thread
Regular price
CHF 495.30
ex VAT
Regular price
Sale price
CHF 495.30
ex VAT
In stock
Price Break
10+
CHF 440.82
19+
CHF 416.05
29+
CHF 411.10
39+
CHF 406.15
49+
CHF 401.19
74+
CHF 396.24
99+
CHF 371.48
199+
CHF 366.52
249+
CHF 361.57
499+
CHF 356.62
999+
CHF 346.71
Couldn't load pickup availability
Description
Description
- Brand / Quality:
- SKF - High Quality
- Thread Size:
- M52x3
- Thread M / F:
- Female
- Thread Direction:
- Left Hand
- Inside Diameter:
- 50mm
- Liner Type:
- PTFE Fabric Lined
Technical
Technical
| d | 50mm |
|---|---|
| d2 max | 114mm |
| G 6H | M52x3 |
| B | 35mm |
| C1 max | 31mm |
| h1 | 195mm |
| a | 6deg |
| Dynamic load C | 440 kN |
| Static load Co | 270 kN |
| Weight | 4.5 kg |
| dk | 66mm |
| d4 | 70mm |
| l3 min | 68mm |
| l4 max | 254mm |
| l5 | 30mm |
| l7 min | 58mm |
| r1 min | 0.6mm |
| w h14 | 60mm |
