SKU: SSUCF.210-32
SSUCF210-32 Imperial Four Bolt Square Stainless Steel Flange Housing with 2 inch Bore Stainless Insert
SSUCF210-32 Imperial Four Bolt Square Stainless Steel Flange Housing with 2 inch Bore Stainless Insert
Regular price
CHF 111.90
ex VAT
Regular price
Sale price
CHF 111.90
ex VAT
In stock
Price Break
10+
CHF 99.59
19+
CHF 94.00
29+
CHF 92.88
39+
CHF 91.76
49+
CHF 90.64
74+
CHF 89.52
99+
CHF 83.93
199+
CHF 82.81
249+
CHF 81.69
499+
CHF 80.57
999+
CHF 78.33
Couldn't load pickup availability
Description
Description
|
UCF or SF Series Stainless Steel 4 Bolt Square Housings: Supplied with a fully sealed stainless steel bearing insert fitted in the stainless steel housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing, food safe and approved, exceptionally strong and durable Note: These bearings will eventually corrode in a marine environment and it is recommended to completely cover with grease or similar protection where practical. Due to the material requirements of these bearings to have a hard-wearing construction, they will be made of a harder form of Stainless Steel, such as 440 or similar, which will be attracted by magnets. Quotations for non-magnetic versions are available upon request. |
- Brand / Quality:
- EU Budget - Economy Quality
- Inside Diameter:
- 50.8mm = 2 inch
- Style:
- SSUCF
- Bolt Hole Centres:
- 111mm
Technical
Technical
| d | 2 inch |
|---|---|
| a | 143mm |
| e | 111mm |
| i | 22mm |
| g | 18mm |
| L | 40mm |
| S | 16mm |
| Z | 54.6mm |
| Bi | 51.6mm |
| n | 19mm |
| Bolt | 16mm |
| Weight | 2.5 kg |
| Dynamic load | 2750 kgf |
| Static load | 2020 kgf |
