SKU: SSUCF.211-32
SSUCF211-32 Imperial Four Bolt Square Stainless Steel Flange Housing with 2 inch Bore Stainless Insert
SSUCF211-32 Imperial Four Bolt Square Stainless Steel Flange Housing with 2 inch Bore Stainless Insert
Regular price
CHF 126.00
ex VAT
Regular price
Sale price
CHF 126.00
ex VAT
In stock
Price Break
3+
CHF 100.09
4+
CHF 94.46
9+
CHF 93.34
19+
CHF 92.21
49+
CHF 91.09
99+
CHF 89.96
499+
CHF 84.34
999+
CHF 83.22
1999+
CHF 82.09
2999+
CHF 80.97
4999+
CHF 78.72
Description
Description
|
UCF or SF Series Stainless Steel 4 Bolt Square Housings: Supplied with a fully sealed stainless steel bearing insert fitted in the stainless steel housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing, food safe and approved, exceptionally strong and durable Note: These bearings will eventually corrode in a marine environment and it is recommended to completely cover with grease or similar protection where practical. Due to the material requirements of these bearings to have a hard-wearing construction, they will be made of a harder form of Stainless Steel, such as 440 or similar, which will be attracted by magnets. Quotations for non-magnetic versions are available upon request. |
- Brand / Quality:
- EU Budget - Economy Quality
- Inside Diameter:
- 50.8mm = 2 inch
- Style:
- SSUCF
- Bolt Hole Centres:
- 130mm
Technical
Technical
| d | 2 inch |
|---|---|
| a | 162mm |
| e | 130mm |
| i | 25mm |
| g | 20mm |
| L | 43mm |
| S | 19mm |
| Z | 58.4mm |
| Bi | 55.6mm |
| n | 22.2mm |
| Bolt | 16mm |
| Weight | 3.4 kg |
| Dynamic load | 3400 kgf |
| Static load | 2550 kgf |
