SKU: SSUCT.206
SSUCT206 Metric Stainless Steel Take Up Unit Housing with 30mm Bore Stainless Insert
SSUCT206 Metric Stainless Steel Take Up Unit Housing with 30mm Bore Stainless Insert
Regular price
CHF 48.00
ex VAT
Regular price
Sale price
CHF 48.00
ex VAT
Equivalent to: ST30
In stock
Price Break
3+
CHF 38.02
4+
CHF 35.88
9+
CHF 35.46
19+
CHF 35.03
49+
CHF 34.60
99+
CHF 34.18
499+
CHF 32.04
999+
CHF 31.61
1999+
CHF 31.19
2999+
CHF 30.76
4999+
CHF 29.90
Description
Description
|
SSUCT or ST Series Stainless Steel Take up Units: Supplied with a fully sealed stainless steel bearing insert fitted in the stainless steel housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing, food safe and approved, exceptionally strong and durable Note: These bearings will eventually corrode in a marine environment and it is recommended to completely cover with grease or similar protection where practical. Due to the material requirements of these bearings to have a hard-wearing construction, they will be made of a harder form of Stainless Steel, such as 440 or similar, which will be attracted by magnets. Quotations for non-magnetic versions are available upon request. |
Equivalent: ST30
- Brand / Quality:
- EU Budget - Economy Quality
- Inside Diameter:
- 30mm
- Style:
- SSUCT
Technical
Technical
| d | 30mm |
|---|---|
| o | 16mm |
| g | 10mm |
| p | 56mm |
| q | 37mm |
| s | 22mm |
| b | 57mm |
| K | 12mm |
| e | 89mm |
| a | 102mm |
| w | 113mm |
| j | 37mm |
| l | 28mm |
| h | 70mm |
| Bi | 38.1mm |
| n | 15.9mm |
| Weight | 1.3 kg |
| Dynamic load | 1520 kgf |
| Static load | 1020 kgf |
| Rec max speed | 5300 rpm |
