SKU: TL60-H-100
TL60-H-100 - 1/2 inch Pitch 60 Tooth Tapered Bore Cast Iron Timing Pulley for 1 inch Wide Belts
TL60-H-100 - 1/2 inch Pitch 60 Tooth Tapered Bore Cast Iron Timing Pulley for 1 inch Wide Belts
Regular price
CHF 72.00
ex VAT
Regular price
Sale price
CHF 72.00
ex VAT
Equivalent to: TL60H100
In stock
Price Break
3+
CHF 57.09
5+
CHF 53.88
9+
CHF 53.24
19+
CHF 52.60
49+
CHF 51.96
74+
CHF 51.32
99+
CHF 48.11
199+
CHF 47.47
249+
CHF 46.83
499+
CHF 46.19
999+
CHF 44.90
Description
Description
Imperial Taper Bore Timing Pulley: Imperial timing pulleys are available in both taper and pilot bore. The pulleys depending on the size are made from either Aluminium 6082, C45 Steel with black oxide treated surface or Cast Iron EN-GJL-200 and black phosphate. Where applicable flanges are made from S235JR Steel. Timing belt life can be increased with the proper pulley reducing running costs of your machinery.
Benefits: Available in a wide range of diameters and number of teeth along with standard widths.
Equivalent: TL60H100
- Brand / Quality:
- Drive-Flex - High Quality
- Teeth:
- 60
- Material:
- Cast Iron
- Belt Width Approx:
- 25.4mm = 1 inch
- Pitch:
- 12.7mm = 0.5 (1/2) inch
- Item Type:
- Flangeless Tapered Bore Pulley
Technical
Technical
| No. teeth | 60 |
|---|---|
| Dp | 242.55mm |
| De | 241.18mm |
| Dm | 106mm |
| F | 34mm |
| Material | Cast Iron |
| Bore | Tapered Bore |
| Belt Width | 25.4mm = 1 inch |
| Pitch | 12.7mm = 0.5 (1/2) inch |
| S | 32mm |
| R | 1mm |
| Di | 223mm |
| Bush | 2012 |
