SKU: UC.215
UC215 Metric Bearing Insert with 75mm Bore 130mm Outside Dia
UC215 Metric Bearing Insert with 75mm Bore 130mm Outside Dia
Regular price
CHF 19.00
ex VAT
Regular price
Sale price
CHF 19.00
ex VAT
In stock
Price Break
3+
CHF 14.94
4+
CHF 14.10
9+
CHF 13.94
19+
CHF 13.77
49+
CHF 13.60
99+
CHF 13.43
499+
CHF 12.59
999+
CHF 12.42
1999+
CHF 12.26
2999+
CHF 12.09
4999+
CHF 11.75
Share this product
Description
Description
|
UC or 10 -- G Series: Normal duty bearing insert with 2 grub screws to allow tightening against the shaft once fitted.
These inserts are ideal replacements for housed types which can easily be removed from the housings when replacement is required |
- Brand / Quality:
- EU Budget - Economy Quality
- Inside Diameter:
- 75mm
- Outside Diameter:
- 130mm
- Style:
- UC
Technical
Technical
| d | 75mm |
|---|---|
| D | 130mm |
| Bi | 77.8mm |
| Be | 30mm |
| n | 33.3mm |
| m | 44.5mm |
| G | 12mm |
| Grub screw | 7/16"-20 UNF |
| Weight | 2.12 kg |
| Dynamic load | 5190 kgf |
| Static load | 4190 kgf |
