SKU: UCFC.208
UCFC208 Metric Four Bolt Cast Iron Round Flanged Housing with 40mm Insert
UCFC208 Metric Four Bolt Cast Iron Round Flanged Housing with 40mm Insert
Regular price
CHF 11.00
ex VAT
Regular price
Sale price
CHF 11.00
ex VAT
In stock
Price Break
3+
CHF 8.00
4+
CHF 7.55
9+
CHF 7.46
19+
CHF 7.37
49+
CHF 7.28
99+
CHF 7.19
499+
CHF 6.74
999+
CHF 6.65
1999+
CHF 6.56
2999+
CHF 6.47
4999+
CHF 6.29
Description
Description
|
UCFC Series 4 Bolt Round Cast Iron Housings: Bearing unit supplied with a fully sealed bearing insert fitted in the round cast iron housing and includes a grease nipple to facilitate re-lubrication, this style has the benefit of a shouldered back face to facilitate location of the housing prior to fastening in place. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing |
- Brand / Quality:
- EU Budget - Economy Quality
- Inside Diameter:
- 40mm
- Style:
- UCFC
- Pitch Circle Diameter:
- 120mm
Technical
Technical
| d | 40mm |
|---|---|
| a | 145mm |
| P | 120mm |
| e | 84.8mm |
| i | 11mm |
| L | 36mm |
| s | 14mm |
| j | 10mm |
| k | 9mm |
| g | 26mm |
| f | 100mm |
| z | 41.2mm |
| Bi | 49.2mm |
| n | 19mm |
| Bolt Size | M12 |
| Weight | 2 kg |
| Dynamic load | 2560 kgf |
| Static load | 1810 kgf |
