SKU: UCFL212D1-NTN
NTN UCFL212D1 Metric Two Bolt Oval Cast Iron Flange Housing with 60mm Bore Insert
NTN UCFL212D1 Metric Two Bolt Oval Cast Iron Flange Housing with 60mm Bore Insert
Regular price
CHF 128.00
ex VAT
Regular price
Sale price
CHF 128.00
ex VAT
In stock
Price Break
3+
CHF 101.58
4+
CHF 95.87
9+
CHF 94.73
19+
CHF 93.59
49+
CHF 92.45
99+
CHF 91.30
499+
CHF 85.60
999+
CHF 84.46
1999+
CHF 83.31
2999+
CHF 82.17
4999+
CHF 79.89
Description
Description
|
UCFL or SFT Series 2 Bolt Oval Cast Iron Housings: Bearing unit supplied with a fully sealed bearing insert fitted in the oval cast iron housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing |
- Brand / Quality:
- NTN - High Quality
- Inside Diameter:
- 60mm
- Style:
- UCFL
- Bolt Hole Centres:
- 202mm
Technical
Technical
| --- | Dimensions |
|---|---|
| Shaft diameter | 60mm |
| H | 250mm |
| J | 202mm |
| A<sub>2</sub> | 29mm |
| A<sub>1</sub> | 18mm |
| A | 48mm |
| N | 23mm |
| L | 140mm |
| A<sub>0</sub> | 68.7mm |
| B | 65.1mm |
| S | 25.4mm |
| Fixing bolt | M20 |
| --- | Load rating |
| Dynamic load C<sub>r</sub> | 58 kN |
| Static load C<sub>0r</sub> | 36 kN |
| Fatigue load limit C<sub>u</sub> | 2.83 kN |
| --- | Unit information |
| Mass | 3.8 kg |
