SKU: UCFX05D1-NTN
NTN UCFX05D1 Metric Four Bolt Square Cast Iron Flange Housing with 25mm Bore Insert
NTN UCFX05D1 Metric Four Bolt Square Cast Iron Flange Housing with 25mm Bore Insert
Regular price
CHF 36.00
ex VAT
Regular price
Sale price
CHF 36.00
ex VAT
In stock
Price Break
3+
CHF 27.98
4+
CHF 26.41
9+
CHF 26.10
19+
CHF 25.78
49+
CHF 25.47
99+
CHF 25.15
499+
CHF 23.58
999+
CHF 23.27
1999+
CHF 22.95
2999+
CHF 22.64
4999+
CHF 22.01
Description
Description
|
UCFX or MSF Series 4 Bolt Square Cast Iron Housings: Bearing unit supplied with a fully sealed bearing insert fitted in the cast iron housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing |
- Brand / Quality:
- NTN - High Quality
- Inside Diameter:
- 25mm
- Style:
- UCFX
- Bolt Hole Centres:
- 83mm
Technical
Technical
| --- | Dimensions |
|---|---|
| Shaft diameter | 25mm |
| L | 108mm |
| J | 83mm |
| A<sub>2</sub> | 18mm |
| A<sub>1</sub> | 13mm |
| A | 30mm |
| N | 12mm |
| A<sub>0</sub> | 40.2mm |
| B | 38.1mm |
| S | 15.9mm |
| Fixing bolt | M10 |
| --- | Load rating |
| Dynamic load C<sub>r</sub> | 21.6 kN |
| Static load C<sub>0r</sub> | 11.3 kN |
| Fatigue load limit C<sub>u</sub> | 0.795 kN |
| --- | Unit information |
| Mass | 1.1 kg |
