SKU: UCFX12D1-NTN
NTN UCFX12D1 Metric Four Bolt Square Cast Iron Flange Housing with 60mm Bore Insert
NTN UCFX12D1 Metric Four Bolt Square Cast Iron Flange Housing with 60mm Bore Insert
Regular price
CHF 88.00
ex VAT
Regular price
Sale price
CHF 88.00
ex VAT
In stock
Price Break
3+
CHF 70.01
4+
CHF 66.07
9+
CHF 65.29
19+
CHF 64.50
49+
CHF 63.71
99+
CHF 62.93
499+
CHF 59.00
999+
CHF 58.21
1999+
CHF 57.42
2999+
CHF 56.64
4999+
CHF 55.06
Description
Description
|
UCFX or MSF Series 4 Bolt Square Cast Iron Housings: Bearing unit supplied with a fully sealed bearing insert fitted in the cast iron housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing |
- Brand / Quality:
- NTN - High Quality
- Inside Diameter:
- 60mm
- Style:
- UCFX
- Bolt Hole Centres:
- 149mm
Technical
Technical
| --- | Dimensions |
|---|---|
| Shaft diameter | 60mm |
| L | 187mm |
| J | 149mm |
| A<sub>2</sub> | 34mm |
| A<sub>1</sub> | 21mm |
| A | 59mm |
| N | 19mm |
| A<sub>0</sub> | 73.7mm |
| B | 65.1mm |
| S | 25.4mm |
| Fixing bolt | M16 |
| --- | Load rating |
| Dynamic load C<sub>r</sub> | 63.5 kN |
| Static load C<sub>0r</sub> | 40 kN |
| Fatigue load limit C<sub>u</sub> | 3.15 kN |
| --- | Unit information |
| Mass | 6.4 kg |
