SKU: UCFX16D1-NTN
NTN UCFX16D1 Metric Four Bolt Square Cast Iron Flange Housing with 80mm Bore Insert
NTN UCFX16D1 Metric Four Bolt Square Cast Iron Flange Housing with 80mm Bore Insert
Regular price
CHF 167.00
ex VAT
Regular price
Sale price
CHF 167.00
ex VAT
In stock
Price Break
3+
CHF 132.54
4+
CHF 125.09
9+
CHF 123.60
19+
CHF 122.11
49+
CHF 120.63
99+
CHF 119.14
499+
CHF 111.69
999+
CHF 110.20
1999+
CHF 108.71
2999+
CHF 107.22
4999+
CHF 104.24
Description
Description
|
UCFX or MSF Series 4 Bolt Square Cast Iron Housings: Bearing unit supplied with a fully sealed bearing insert fitted in the cast iron housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing |
- Brand / Quality:
- NTN - High Quality
- Inside Diameter:
- 80mm
- Style:
- UCFX
- Bolt Hole Centres:
- 171mm
Technical
Technical
| --- | Dimensions |
|---|---|
| Shaft diameter | 80mm |
| L | 214mm |
| J | 171mm |
| A<sub>2</sub> | 40mm |
| A<sub>1</sub> | 24mm |
| A | 70mm |
| N | 23mm |
| A<sub>0</sub> | 91.6mm |
| B | 85.7mm |
| S | 34.1mm |
| Fixing bolt | M20 |
| --- | Load rating |
| Dynamic load C<sub>r</sub> | 92 kN |
| Static load C<sub>0r</sub> | 64 kN |
| Fatigue load limit C<sub>u</sub> | 4.6 kN |
| --- | Unit information |
| Mass | 11 kg |
