SKU: UELFL204D1-NTN
NTN UELFL204D1 Metric Two Bolt Cast Iron Oval Housing with 20mm Bore Eccentric Collar Insert - Allow 2-3 Days
NTN UELFL204D1 Metric Two Bolt Cast Iron Oval Housing with 20mm Bore Eccentric Collar Insert - Allow 2-3 Days
Regular price
CHF 35.00
ex VAT
Regular price
Sale price
CHF 35.00
ex VAT
In stock
Price Break
3+
CHF 30.69
4+
CHF 29.45
9+
CHF 28.83
19+
CHF 27.90
49+
CHF 27.28
99+
CHF 25.73
499+
CHF 21.70
999+
CHF 0.00
1999+
CHF 0.00
2999+
CHF 0.00
4999+
CHF 0.00
Share this product
Description
Description
UELFL200 Series 2 Bolt Cast Iron Oval Housings: These bearing units are supplied with a fully sealed bearing insert fitted in the oval cast iron housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has an eccentric collar to allow tightening against the shaft once fitted. The inserts can be removed from the housings for future replacement as required.
Benefits: Can be re-lubricated, replaceable bearing insert, eccentric collar fixing
- Brand / Quality:
- NTN - High Quality
- Inside Diameter:
- 20mm
- Style:
- UELFL
- Bolt Hole Centres:
- 90mm
Technical
Technical
| Shaft diameter | 20mm |
|---|---|
| H | 113mm |
| J | 90mm |
| A<sub>2</sub> | 15mm |
| A<sub>1</sub> | 11mm |
| A | 25.5mm |
| N | 12mm |
| L | 60mm |
| A<sub>0</sub> | 41.6mm |
| B<sub>1</sub> | 43.7mm |
| S | 17.1mm |
| F min. | 34mm |
| Fixing bolt | M10 |
| Mass | 0.5 kg |
