SKU: UKC312H-SNR
SNR UKC312H Metric Cast Iron Cartridge Unit with Adaptor Sleeve Mounted and 55mm Bore Insert 46mm Outside Dia - Allow 2-3 Days
SNR UKC312H Metric Cast Iron Cartridge Unit with Adaptor Sleeve Mounted and 55mm Bore Insert 46mm Outside Dia - Allow 2-3 Days
Regular price
CHF 248.00
ex VAT
Regular price
Sale price
CHF 248.00
ex VAT
In stock
Price Break
3+
CHF 219.42
4+
CHF 210.56
9+
CHF 206.13
19+
CHF 199.48
49+
CHF 195.04
99+
CHF 183.96
499+
CHF 155.15
999+
CHF 0.00
1999+
CHF 0.00
2999+
CHF 0.00
4999+
CHF 0.00
Share this product
Description
Description
UKC Series (Medium Duty) Cartridge Bearing Unit with Adaptor Sleeve Mounted: Cast iron cartridge bearing unit supplied with a full width bearing insert fitted and includes a grease nipple to facilitate re-lubrication. Cartridge units allow a self aligning bearing inserts to be used where a fixed bearing would normally be used.
The insert can be removed from the housings for future replacement as required
Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, full width insert
- Brand / Quality:
- NTN - High Quality
- Inside Diameter:
- 55mm
- Style:
- UKC
Technical
Technical
| --- | Dimensions |
|---|---|
| Shaft diameter d | 55mm |
| A | 46mm |
| A3 | 2.5mm |
| B1 | 62mm |
| d1 | 80mm |
| H | 160mm |
| s1 | 36.5mm |
| G | M6x1 |
| --- | Load rating |
| Dynamic load C | 81.6 kN |
| Static load C0 | 51.8 kN |
| --- | Unit information |
| Operating temperature min. | -20°C |
| Operating temperature max. | 100°C |
| Mass | 4.77 kg |
