SKU: UKC319H-SNR
SNR UKC319H Metric Cast Iron Cartridge Unit with Adaptor Sleeve Mounted and 85mm Bore Insert 72mm Outside Dia - Allow 2-3 Days
SNR UKC319H Metric Cast Iron Cartridge Unit with Adaptor Sleeve Mounted and 85mm Bore Insert 72mm Outside Dia - Allow 2-3 Days
Regular price
CHF 627.00
ex VAT
Regular price
Sale price
CHF 627.00
ex VAT
In stock
Price Break
3+
CHF 532.83
4+
CHF 504.78
9+
CHF 476.74
19+
CHF 448.70
49+
CHF 437.48
99+
CHF 426.26
499+
CHF 370.17
999+
CHF 0.00
1999+
CHF 0.00
2999+
CHF 0.00
4999+
CHF 0.00
Share this product
Description
Description
UKC Series (Medium Duty) Cartridge Bearing Unit with Adaptor Sleeve Mounted: Cast iron cartridge bearing unit supplied with a full width bearing insert fitted and includes a grease nipple to facilitate re-lubrication. Cartridge units allow a self aligning bearing inserts to be used where a fixed bearing would normally be used.
The insert can be removed from the housings for future replacement as required
Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, full width insert
- Brand / Quality:
- NTN - High Quality
- Inside Diameter:
- 85mm
- Style:
- UKC
Technical
Technical
| --- | Dimensions |
|---|---|
| Shaft diameter d | 85mm |
| A | 72mm |
| A3 | 3mm |
| B1 | 90mm |
| d1 | 125mm |
| H | 240mm |
| s1 | 52mm |
| G | M10x1 |
| --- | Load rating |
| Dynamic load C | 156 kN |
| Static load C0 | 122 kN |
| --- | Unit information |
| Operating temperature min. | -20°C |
| Operating temperature max. | 100°C |
| Mass | 15.7 kg |
