SKU: UKC328H-SNR

SNR UKC328H Metric Cast Iron Cartridge Unit with Adaptor Sleeve Mounted and 125mm Bore Insert 100mm Outside Dia - Allow 2-3 Days

SNR UKC328H Metric Cast Iron Cartridge Unit with Adaptor Sleeve Mounted and 125mm Bore Insert 100mm Outside Dia - Allow 2-3 Days
Regular price CHF 2,137.00 ex VAT
Regular price Sale price CHF 2,137.00 ex VAT
Sale Sold out

In stock

Price Break
3+ CHF 1,817.05
4+ CHF 1,721.41
9+ CHF 1,625.78
19+ CHF 1,530.14
49+ CHF 1,491.89
99+ CHF 1,453.64
499+ CHF 1,262.37
999+ CHF 0.00
1999+ CHF 0.00
2999+ CHF 0.00
4999+ CHF 0.00
Quantity
Request Quotation

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Technical
--- Dimensions
Shaft diameter d 125mm
A 100mm
A3 4.5mm
B1 131mm
d1 180mm
H 360mm
s1 73mm
G M10x1
--- Load rating
Dynamic load C 275 kN
Static load C0 272 kN
--- Unit information
Operating temperature min. -20°C
Operating temperature max. 100°C
Mass 50.8 kg
