SKU: VHR-2-1/2
Major Brand VHR2-1/2 Hex Head V-Groove Hi-Roller Bearing 2-1/2 inch Outside Diameter
Major Brand VHR2-1/2 Hex Head V-Groove Hi-Roller Bearing 2-1/2 inch Outside Diameter
Regular price
CHF 167.00
ex VAT
Regular price
Sale price
CHF 167.00
ex VAT
Equivalent to: VHR-250-A VLR-2-1/2 VCF-2-1/2
In stock
Price Break
3+
CHF 132.77
4+
CHF 125.31
9+
CHF 123.82
19+
CHF 122.32
29+
CHF 120.83
39+
CHF 119.34
49+
CHF 111.88
59+
CHF 110.39
249+
CHF 108.90
499+
CHF 107.41
999+
CHF 104.42
Description
Description
|
V-Groove Hi-Roller Bearing: Designed for applications where both radial and thrust loading are present. These bearings are tightly sealed with an expansion plug on one end and radial contact lip seals on the bearings. They are capable of running at much higher speeds than needle bearing cam followers. Benefits: Ideal for use in environments where dust or high moisture is present. |
Equivalent: VHR-250-A VLR-2-1/2 VCF-2-1/2
- Brand / Quality:
- Major Brand - High Quality
- Outside Diameter:
- 63.5mm = 2.5 (2-1/2) inch
- Width:
- 33.35mm = 1.313 inch
Technical
Technical
| A | 2.5 inch |
|---|---|
| B | 1.313 inch |
| F | 1.5 inch |
| G | 0.688 inch |
| K | 0.75 inch |
| L | 1.75 inch |
| M | 0.875 inch |
| Thread class 2A N | 3/4-16 UNF |
| R | 1 inch |
| S | 0.062 inch |
| Basic dynamic rating | 2750 lbs |
| Dynamic thrust load rating | 1700 lbs |
| Max static capacity | 1100 lbs |
