SKU: WLT20-60-500-DURB
Durbal WLT20-60-500 Stainless Steel Spherical Plain Bearing with Cage 20x50x25mm
Durbal WLT20-60-500 Stainless Steel Spherical Plain Bearing with Cage 20x50x25mm
Regular price
CHF 373.11
ex VAT
Regular price
Sale price
CHF 373.11
ex VAT
In stock
Price Break
5+
CHF 369.38
10+
CHF 354.45
20+
CHF 346.99
50+
CHF 335.80
100+
CHF 328.34
500+
CHF 309.68
1000+
CHF 261.18
Couldn't load pickup availability
Description
Description
DURBAL Heavy-Duty Caged Stainless Steel Spherical Bearings with Integral Self-Aligning Roller Bearing: These spherical bearings are made from hardened and super finished stainless steel. For high speeds, wide swivelling angles or rotating movements. Suitable for high loads. Low maintenance due to long-term lubrication with food-grade approval. Covering discs in stainless steel on both sides to prevent the penetration of coarse dirt particles inside the bearing. Temperature range: -45 deg C to +120 deg C.
- Brand / Quality:
- Durbal - High Quality
- Inside Diameter:
- 20mm
Technical
Technical
| d | 20mm |
|---|---|
| D | 50mm |
| B | 25mm |
| C | 18mm |
| d1 | 24.3mm |
| tilt angle α | 7 deg |
| weight | 0.21kg |
| rotational speed limit n max | 825 min-1 |
| basic load rating dyn C | 11.9 kN |
| basic load rating stat Co | 8.19 kN |
| radial clearance CN | 10-30 µm |
