Durbal WLT35-00-500 Steel Spherical Plain Bearing with Cage 35x92x48mm
Durbal WLT35-00-500 Steel Spherical Plain Bearing with Cage 35x92x48mm
Regular price
CHF 846.83
ex VAT
Regular price
Sale price
CHF 846.83
ex VAT
In stock
Price Break
2+
CHF 804.49
5+
CHF 762.15
10+
CHF 719.81
15+
CHF 677.46
20+
CHF 660.53
30+
CHF 643.59
50+
CHF 558.91
Couldn't load pickup availability
Description
Description
DURBAL Heavy-Duty Caged Spherical Bearings with Integral Self-Aligning Roller Bearing: These spherical bearings are made from hardened and super finished steel. For high speeds, wide swivelling angles or rotating movements. Suitable for high loads. Low maintenance due to long-term lubrication with food-grade approval. Covering discs on both sides to prevent the penetration of coarse dirt particles inside the bearing. Temperature range: -45 deg C to +120 deg C.
- Brand / Quality:
- Durbal - High Quality
- Inside Diameter:
- 35mm
Technical
Technical
| d | 35mm |
|---|---|
| D | 92mm |
| B | 48mm |
| C | 35mm |
| d1 | 44.5mm |
| tilt angle α | 7 deg |
| weight | 1.35kg |
| rotational speed limit n max | 400 min-1 |
| basic load rating dyn C | 50.1 kN |
| basic load rating stat Co | 37 kN |
| radial clearance CN | 10-30 µm |
