SKU: WS016-JUB
WS016 Zinc Plated Steel Jubilee Wingspade Clip Adjustment Range 11mm-16mm Band Width 9.9mm
WS016 Zinc Plated Steel Jubilee Wingspade Clip Adjustment Range 11mm-16mm Band Width 9.9mm
Regular price
CHF 3.75
ex VAT
Regular price
Sale price
CHF 3.75
ex VAT
Low stock
Price Break
5+
CHF 2.63
10+
CHF 2.25
20+
CHF 2.06
50+
CHF 1.88
100+
CHF 1.50
500+
CHF 1.31
1000+
CHF 1.13
Couldn't load pickup availability
Description
Description
Zinc Plated Steel Jubilee Wingspade Clips: Jubilee Wingspade® Clips have a thumb screw for fitting easily by hand. Suitable where repeated tightening/loosening/removing of the clip are required such as garden hoses and other domestic applications.
Benefits: Easy to fit by hand using thumb and forefinger.
- Brand / Quality:
- Jubilee - High Quality
- Width:
- 9.9mm
- Min Adjustment Range:
- 11mm
- Max Adjustment Range:
- 16mm
Technical
Technical
| Adjustment Range | 11mm - 16mm |
|---|---|
| Band Width (+/- 0.1) | 9.9mm |
| Band Thickness (+/- 0.1) | 0.762mm |
| Recommended Torque | 3.4Nm |
| Maximum Torque | 4.5Nm |
| Maximum Pressure | 182 Psi |
