SKU: WSZC12-JCS
JCS WSZC12 Zinc Plated Steel Hi-Grip Wing Screw Adjustment Range 9.5-12mm Band Width 9mm
JCS WSZC12 Zinc Plated Steel Hi-Grip Wing Screw Adjustment Range 9.5-12mm Band Width 9mm
Regular price
CHF 5.00
ex VAT
Regular price
Sale price
CHF 5.00
ex VAT
In stock
Price Break
3+
CHF 3.97
5+
CHF 3.75
9+
CHF 3.71
19+
CHF 3.66
49+
CHF 3.62
74+
CHF 3.57
99+
CHF 3.35
199+
CHF 3.30
249+
CHF 3.26
499+
CHF 3.22
999+
CHF 3.13
Description
Description
Zinc Plated Steel Hi-Grip Wing Screw: Specifically designed for frequently removed hoses, the unique dovetail locking and side lugs of the wing plate ensure excellent sealing and longevity. Used for a wide variety of domestic, automotive and industrial applications, the standard Hi-Grip hose clip is made from mild steel, electroplated, passivated and tested to EN9227. Hi-Grip general-purpose worm drive hose clips are widely regarded for their quality, durability and ability to withstand a great deal of abuse.
- Brand / Quality:
- JCS - High Quality
- Width:
- 9mm
- Min Adjustment Range:
- 9.5mm
- Max Adjustment Range:
- 12mm
Technical
Technical
| BS No. | 12 |
|---|---|
| Adjustment Range (mm) | 9.5-12mm |
| Adjustment Range (inch) | 3/8 - 1/2 inch |
| A | 7mm |
| B | 31mm |
| C | 10mm |
| D | 12mm |
| E | 9mm |
| F | 0.7mm |
| G | 24mm |
| Recommended Torque Nm | 3Nm |
| Recommended Torque lb-in | 26lb-in |
